We fulfilled 1 order for Low Headroom European Wire Rope Hoist from Philippines. This is a 3 ton electric wire rope hoist, the hoisting motor is SZW brand, Squirrel Cage and Frequency Conversion Hoist Motor. Protection class IP54 Insulation class F. Totally enclosed type with Splash Lubrication Electromagnetic disc type brake system. Maintenance free. After the production is completed in the crane factory in China, it is shipped to the Philippines by sea at the Qingdao port
| Rated lifting capacity | t | 3 | |
| Lifting height | m | 20 | |
| Speed | Hoist traveling speed | m/min | 5~20 (inverter control) |
| Lifting speed | 1.6~16 (inverter control) | ||
| Working class | / | M5 | |
| Power supply | V/Hz/Ph | 240V 50Hz 3Ph | |
| Control voltage | V | 36 | |
| Hoist traveling power | KW | 0.4 | |
| Hoisting power | 11 | ||
| Total power | 11.4 | ||
| Recommended track width | mm | 200-400 | |
| Wire rope diameter | mm | 11 | |
| Total Weight | kg | 580 | |
| Protection class | / | IP54 | |
| Insulation grade | / | F | |
| Ambient temperature | / | -20℃-+40℃ | |
| Control method | / | Pendant control | |
| Country of origin | / | China | |
Our products have passed CE (ECM) and ISO Certifications, and you can also specify a third-party agency for quality testing. Fees of third-party testing are not included in this offer.
We are a crane manufacturer located in China, providing crane customization services to global crane customers. If you want to customize a electric hoist, you can leave a message on the website or Email: sales010@cranesdq.com, tell us the following information, and our sales manager will contact you:
