45t40m rail-mounted container gantry crane, as an indispensable and efficient loading and unloading equipment for modern ports and logistics centers, has attracted much attention in the industry for its excellent performance and wide application fields. This crane is designed for handling large containers. With its powerful lifting capacity and precise operation control, it greatly improves the efficiency and safety of cargo loading and unloading. From the precise mechanical structure to the intelligent control system, every detail demonstrates technological innovation and ingenuity. This manual aims to comprehensively introduce the various characteristics, operating guidelines, safety specifications and maintenance points of the crane, and provide users with detailed reference and guidance to help them be at ease in busy logistics operations and create more value.
45t40m rail-mounted container gantry crane (hereinafter referred to as "crane") is an efficient and heavy-duty container loading and unloading equipment designed for modern ports, logistics parks and large cargo yards. The "45t" in its name represents the maximum lifting weight capacity, and the "40m" refers to the crane span, which can meet the loading and unloading needs of containers of different sizes. Through a precise control system and a stable mechanical structure, the crane achieves efficient and safe operating performance.
The crane adopts advanced structural design, with the characteristics of high strength, light weight and corrosion resistance. Its structure mainly includes the main beam, end beam, operating mechanism and lifting mechanism, with the characteristics of simple structure, stable operation and convenient maintenance. The crane also adopts an intelligent control system, with the characteristics of high automation, easy operation and high safety. Through precise control system and stable mechanical structure, the crane achieves efficient and safe operation performance.
The design of this 45-ton 40-meter rail-mounted container gantry crane fully considers the efficient operation and environmental protection requirements of modern port logistics. Its main beam made of high-strength steel not only ensures the structural safety and stability when bearing a heavy load of up to 45 tons, but also achieves the goal of maximizing the operating efficiency in a limited space through optimized design. The connection structure between the main beam and the end beam is stable and reliable, ensuring that the operating posture of the whole machine remains horizontal under various working conditions.
The advanced electrical control system is one of the core highlights of the crane. The PLC programmable logic controller and intelligent sensor technology are used to achieve accurate positioning and high-speed response of the spreader, whether it is fine-tuning operation or heavy load rapid loading and unloading, it can be accurate. At the same time, the system has a complete fault diagnosis function, which can identify and warn potential faults in the first time, effectively reduce maintenance costs and ensure long-term stable operation of the equipment.
In order to meet the growing demand for green and sustainable development, this crane has been deeply optimized in the power system. The use of energy-saving motor drive and variable frequency speed regulation technology not only reduces energy consumption, but also greatly reduces carbon emissions, meeting the requirements of current and future environmental protection regulations. In addition, the crane is also equipped with an energy recovery device, which can convert kinetic energy into electrical energy for storage during actual operation, further improving the overall energy efficiency performance.
This 45-ton 40-meter rail-mounted container gantry crane is widely used in various scenarios, including but not limited to large ports, logistics parks, railway freight yards, and large industrial warehouses. Its powerful lifting capacity and flexible span adjustment capabilities enable it to easily cope with the needs of various complex operating environments. Whether it is loading and unloading, stacking or transshipment operations of containers, this crane can demonstrate efficient, safe and reliable operating performance, becoming an indispensable and important equipment in modern logistics and warehousing facilities.
The main technical parameters of this 45-ton 40-meter rail-mounted container gantry crane include a maximum lifting weight of 45 tons, a span of 40 meters, a lifting height customized according to customer needs, operating speed and acceleration, etc. In addition, the crane is also equipped with advanced electrical control systems, safety protection devices, fault diagnosis systems and other equipment to ensure stable operation and efficient operation of the equipment.
Main technical parameters (45t40m rail-mounted container gantry crane)
| Parameter name | Parameter value/description |
| Maximum lifting weight | 45 tons |
| Span | 40 meters |
| Lifting height | Customized according to customer needs |
| Running speed and acceleration | _ |
| Main beam material | High-strength steel |
| Control system | PLC programmable logic controller + smart sensor |
| Power system | Energy-saving motor drive + frequency conversion speed regulation technology |
| Energy recovery device | Provide |
| Safety protection device | Provide |
| Fault diagnosis system | Equipped with complete fault diagnosis function |
| Application Areas and Scenarios | Large ports, logistics parks, railway freight yards, etc. |
| Equipment features and advantages | High strength, light weight, corrosion resistance, etc. |
Electrical control system and technical highlights
| System/Technical Name | Description and Features |
| PLC controller | Programmable logic controller for precise control |
| Smart sensors | Real-time monitoring of the spreader status to achieve high-speed response |
| Precision positioning technology | Whether it is fine-tuning operations or heavy-duty loading and unloading, it can be accurate |
| Fault diagnosis function | Identify and warn of potential failures to reduce maintenance costs |
| Energy-saving motor drive | Reduce energy consumption and reduce carbon emissions |
| Frequency conversion speed control technology | Adjust the motor speed according to the operation needs to improve energy efficiency |
| Energy recovery device | Convert kinetic energy into electrical energy storage to improve overall energy efficiency |
| System integration and stability | The structure is stable to ensure stable operation under various operating conditions |
| Ease of operation and safety | High degree of automation, easy operation, high security |
The main beam of the crane is a key component for carrying and transmitting operating loads. Its structure is designed as a box-type section, which not only has sufficient strength, but also significantly enhances the rigidity and stability of the structure by filling it with high-strength steel, such as carbon steel or alloy steel, to cope with various complex working conditions and heavy load requirements. This design ensures that the main beam can maintain a stable shape when subjected to external forces, without excessive deformation or vibration, thereby ensuring the safety and efficiency of the lifting operation.
The end beam is closely connected to the main beam through connectors to form a strong and stable frame structure. This connection method not only ensures the relative position stability between the main beam and the end beam, but also enables the entire crane to maintain the stability of the overall structure during operation, thereby improving the reliability and service life of the equipment. Horizontal and vertical adjustment devices are also cleverly designed between the main beam and the end beam. These devices allow operators to make precise adjustments according to different operating conditions to ensure the flexibility and adaptability of the crane during operation.
The hoisting mechanism of the crane is the core working part, which adopts the motor drive system and realizes precise control through the high-efficiency reducer and brake. The operating mechanism includes the trolley travel mechanism and the car travel mechanism, which are responsible for the longitudinal movement of the crane on the track and the lateral movement of the container on the main beam respectively. These mechanisms are equipped with advanced electrical control systems and safety protection devices to ensure the safety and stability of the operation.
The control system of the crane adopts advanced PLC programming technology to realize automatic control and intelligent management. Safety devices include limit switches, overload protection devices, windproof devices and emergency stop buttons, etc., to ensure the safety of the equipment during operation.
The track of the crane needs to be laid on a solid and flat ground, and the track spacing needs to be customized according to the crane model. At the same time, the crane also needs to be equipped with corresponding power supply system, signal system and lighting system to meet the operation requirements.
Before installing the crane, detailed site survey and preparation must be carried out. First, use professional measuring tools to accurately measure the track spacing to ensure that it meets the design requirements and actual site needs; check whether the ground is flat and whether the ground bearing capacity meets the equipment weight and operation requirements, and adjust or reinforce the ground flatness if necessary; prepare necessary installation tools and equipment, such as cranes, wrenches, screwdrivers, jacks, etc., and ensure that all tools and equipment are in good working condition; conduct a comprehensive inspection of the crane, including the wear and lubrication of each component, and the electrical system, etc., to ensure that all components are intact.
The installation steps of the crane include track laying, assembly of main beams and end beams, installation of lifting mechanisms and operating mechanisms, and commissioning of control systems and safety devices. During the installation process, construction is carried out strictly in accordance with the drawings and technical requirements to ensure the stability and safety of the equipment. At the same time, follow the corresponding installation sequence and steps to ensure the smooth progress of the installation process.
After the installation is completed, the crane needs to be fully debugged and tested. First, debug the electrical system to check whether the electrical components are working properly and whether the connection lines are firm and reliable; run-in the mechanical components to check whether the running tracks of the components are accurate and whether the coordination between the components is smooth; test the safety devices to check whether the safety devices are working properly to ensure the safety performance of the equipment. During the trial operation, record the performance indicators and data in detail, including running speed, load capacity, stability, etc., so as to optimize and improve the equipment later.
The installation acceptance of the crane shall be carried out in accordance with relevant standards and specifications. First, check the installation quality of each component, including the track spacing, the verticality of the main beam and the end beam, the fastening of each component, etc.; test the performance parameters of the equipment, including running speed, load capacity, stability, etc.; test the effectiveness of the safety device to ensure the safety performance of the equipment. It can only be officially put into use after passing the acceptance. At the same time, establish the use and maintenance records of the equipment, and regularly inspect and maintain the equipment to ensure the long-term stable operation of the equipment.
Before operating the crane each time, a comprehensive and detailed inspection and preparation must be carried out, which is a key step to ensure safe and efficient operation. First, check the electrical system, including whether the cables, terminals, controllers and other components are normal, whether the power supply is stable and reliable, and whether various indicator lights and alarm devices are intact to ensure that the electrical system can work normally.
Then, carefully check the mechanical parts of the crane, such as tracks, wheels, hooks, pulleys, etc., to check whether there is wear, deformation, breakage, etc., and whether the lubrication is good. The state of these parts directly affects the operation stability and safety of the crane. Check the safety devices, such as overload protection, travel limit switch, emergency stop button, etc., to ensure that these devices can work normally and can protect the safety of equipment and personnel in a timely and effective manner when necessary.
Confirm that there are no obstacles on the running track and ground of the crane to avoid collision or jamming during the lifting operation. At the same time, prepare the necessary operating tools and equipment according to the operation requirements, such as slings, special tools, etc. It is essential to train operators on the equipment operation procedures and safety specifications so that they are familiar with and master the correct operation methods and understand the possible risks and preventive measures. Ensure that all personnel involved in the operation have the necessary skills and knowledge to be able to perform standardized, safe and efficient operations in actual operations.
Start the equipment: Before starting the crane equipment, you must confirm that all control handles and switches are in the off or safe position, and then start each system step by step according to the operating procedures.
Adjust the position of the crane: According to the operation requirements, adjust the position of the crane to ensure that it can move flexibly and dock accurately in the operation area.
Lifting containers: When lifting containers, strictly follow the operating procedures to ensure the safety and stability of the equipment. Pay attention to the operating status of the equipment and changes in the surrounding environment so that timely measures can be taken to deal with emergencies.
Move the container to the designated location: Use the crane's moving function to move the container accurately to the designated location. Also pay attention to the operating status and surrounding environment of the equipment.
Lower the container: When the container arrives at the designated location, lower the container. Also pay attention to the operating status and surrounding environment of the equipment to ensure safe lowering of the container.
During the entire lifting operation, the operation process must be strictly followed to ensure the safety and stability of the equipment. At the same time, pay attention to the operating status of the equipment and the changes in the surrounding environment and take timely measures to deal with emergencies.
In the event of an emergency or equipment failure during the operation, emergency shutdown measures must be taken immediately. In an emergency, the operation should be stopped immediately and the power supply should be cut off to ensure the safety of personnel. In the event of equipment failure, the type of failure and the degree of impact should be determined before deciding whether an emergency shutdown is required. When troubleshooting, relevant specifications should be followed to avoid causing greater losses or safety hazards. For unresolved faults, professional maintenance personnel should be contacted in time for maintenance and treatment, and records should be kept for verification.
Regular maintenance and maintenance work is required to ensure the long-term and stable operation of the crane. This includes cleaning the surface of the equipment, checking the status of the electrical system, mechanical components and safety devices, replacing wear parts and lubricating oil, etc. When cleaning the surface of the equipment, care should be taken to avoid using highly corrosive detergents to avoid damage to the equipment. When checking the status of each component, attention should be paid to details. If wear or damage is found, it should be replaced or repaired in time to ensure safe and reliable operation. In addition, lubricating oil should be replaced regularly to ensure the normal operation of the equipment and extend its service life. It is also very important to establish equipment maintenance files to record each maintenance and maintenance for subsequent analysis and improvement.
Daily Maintenance Checklist
| Inspection items | Inspection content | Inspection criteria | Inspection results |
| Electrical system | Cables, terminal blocks, controllers | No damage, no looseness, working properly | _ |
| Power Stability | The voltage fluctuation range is within the normal range | _ | |
| Indicator lights, alarm devices | In perfect condition, with normal indications | _ | |
| Mechanical components | Rails, wheels, hooks, pulley blocks | No wear, no deformation, no breakage | _ |
| Lubrication condition | Good lubrication, no dry grinding phenomenon | _ | |
| Safety devices | Overload protection, travel limit switch | Normal function, no damage | _ |
| Emergency stop button | It can shut down immediately after pressing | _ | |
| Operating environment | Running tracks, ground | No obstacles, flat and no potholes | _ |
| Operating tools and equipment | Rigging, special tools | Complete, intact, compliant with regulations | _ |
| Cleaning and maintenance | Equipment surface cleaning | No oil, no dust, clean and tidy | _ |
| Lubricating oil condition | Types and quantity of lubricating oil | Use prescribed lubricating oil, sufficient quantity | _ |
| Wear parts inspection | Wear parts condition | No excessive wear and tear, if needed, replace it in time | _ |
| Maintain records | Maintain files | Complete, accurate and traceable records | _ |
Crane troubleshooting and handling table
| Fault type | Possible causes | Troubleshooting method | Treatment measures |
| Electrical failure | Cable damage, loose wiring | Check the cables and terminal blocks to ensure that the connections are good | Replace the damaged cable and fasten the terminal blocks |
| Power problem | Check the power supply voltage to ensure stability and reliability | Adjust the power supply voltage or replace the power supply | |
| Mechanical failure | Parts wear and break | Check mechanical parts, such as rails, wheels, etc. | Replace worn or broken parts |
| Poor lubrication | Check the lubrication condition to ensure adequate lubrication | Replenish or replace lubricating oil | |
| Safety device failure | Protection device failure | Test the function of the protection device to ensure normal operation | Repair or replace failure protection device |
| Improper operation | The operation process is not standardized | Train operators to ensure that they are familiar with the operation process | Strengthen operation specification training |
| Emergency | The safety of personnel or equipment is threatened | Stop the machine immediately and cut off the power supply | Take urgent measures to ensure the safety of personnel |
| Other faults | _ | Check according to specific circumstances | Take appropriate measures according to the results of the investigation |
When operating a crane, a series of operational safety regulations must be strictly followed to ensure the safety of the operation process. First of all, the operator must wear personal protective equipment, including safety helmets, protective glasses, gloves, etc. At the same time, keep the operation area clean and tidy to avoid debris and obstacles that affect the safety of operation. During the operation, avoid overloading operations to avoid overloading the crane or damage to the equipment. In addition, outdoor operations should be avoided in severe weather conditions such as strong winds and heavy rains to avoid accidents.
It is also necessary to communicate and collaborate well with the surrounding personnel. Before operating the crane, ensure that the surrounding personnel understand the operation process and safety precautions and keep a safe distance. During the operation, if assistance or command from others is required, clear language should be used for communication to avoid misunderstandings and misleading. At the same time, pay close attention to changes in the surrounding environment and take timely measures to deal with emergencies.
Personnel operating cranes must undergo professional training and assessment and obtain the corresponding qualification certificates before they can take up their posts. The training content includes equipment operation procedures, safety regulations, emergency response and other aspects. Through training, operators' safety awareness and operating skills are improved to ensure safety during the operation. In addition, operators need to undergo regular refresher training and assessment to ensure that their skills and knowledge always meet the relevant requirements.
The operating environment of the crane must meet certain conditions. Including flat ground, no obstacles, wind speed not exceeding the specified value, etc. Before operation, the operating environment should be fully evaluated and inspected to ensure that the environmental conditions meet the requirements. At the same time, operations should be avoided under extreme weather conditions, such as lightning, heavy rain, etc., to avoid accidents. During the operation, if environmental conditions change, timely measures should be taken to deal with them.
In order to deal with possible emergencies or emergencies, a comprehensive emergency response plan should be formulated. The plan should include emergency shutdown measures, personnel evacuation plans, equipment repair plans, etc. At the same time, the implementation of preventive measures should be strengthened, such as regular inspections of equipment status and strengthening of personnel training. In addition, an emergency rescue team should be established to ensure timely response and handling in emergency situations. By strengthening the implementation of emergency response and preventive measures, the probability of accidents can be effectively reduced and the safety of personnel and the normal operation of equipment can be guaranteed.
To ensure the long-term stable operation and efficient use of the crane, it is crucial to formulate and strictly implement a complete regular maintenance and care plan. The plan should cover the maintenance content and requirements of different time periods, such as regular inspections conducted monthly, in-depth inspections conducted quarterly, and comprehensive maintenance conducted annually or even longer. These periodic maintenance tasks include but are not limited to: corrosion inspection and wear assessment of the crane's structural parts, functional testing and reliability assessment of key components such as hydraulic systems and electrical control systems, and lubrication and wear inspection of all moving parts.
In the actual operation of the crane, a series of common fault problems may be encountered. For these faults, a complete and efficient troubleshooting and solution mechanism needs to be established. When a fault occurs, the fault phenomenon must first be described in detail and accurately, including the time, location, specific manifestations and possible impact range of the fault. Secondly, an in-depth cause analysis should be conducted, which may involve hardware failure, software errors, improper operation and other factors. After finding the cause of the fault, it is necessary to formulate and implement targeted solutions, including isolating the source of the fault, taking temporary measures to ensure the safety of the equipment, and repairing or replacing damaged parts. In order to prevent similar failures from happening again, we need to summarize experience and lessons and develop effective preventive measures.
In order to ensure the stable operation of the crane and reduce the downtime loss caused by equipment damage, the company needs to reserve a certain amount of spare parts in advance. These spare parts include but are not limited to electrical components (such as contactors, relays, sensors, etc.), mechanical parts (such as bearings, gears, chains, etc.), hydraulic components and other specially customized parts. During the replacement of spare parts, strict operating specifications and procedures must be followed to ensure that the newly replaced spare parts are of reliable quality, stable performance and meet relevant national standards. At the same time, in order to reduce procurement costs and ensure the stability of the supply chain, a detailed spare parts procurement guide needs to be established. The guide should clearly list the procurement channels for various types of spare parts, including original suppliers, qualified distributors or agents, etc.; compare the price plans and quality assurance of different channels; set clear procurement processes and quality acceptance standards; according to actual needs and supplier conditions, spare parts inventory planning and early warning mechanisms should be done in advance; for key and commonly used spare parts, it is possible to consider establishing a long-term cooperative relationship or signing a framework contract; actively promote cooperative innovation and technical exchanges with suppliers, and continuously improve procurement efficiency and spare parts quality level.
Standard accessories are the basic components of cranes. Their design and manufacturing comply with relevant national and industry standards to ensure the safe and stable operation of the whole equipment under various working conditions. As the core part, the electrical control system usually includes but is not limited to the control cabinet, operation panel, various sensors, motor drivers, etc. These components work together to achieve precise control and efficient operation of the crane. Safety protection devices are key configurations to ensure the safety of operations, such as overload protectors, limit switches, emergency stop buttons, etc. They can respond quickly and take protective measures in abnormal situations to prevent accidents. Operating tools and equipment accessories include but are not limited to cabs, operating handles, remote controls, special tools, etc. These facilities facilitate operators to perform various operations safely and conveniently.
In addition to standard configurations, cranes also provide a series of flexible optional accessories to meet users' different operating needs and improve equipment performance. For example, the remote monitoring system is an important optional accessory. By installing this system, users can remotely monitor the operating status, cargo weight, location information and other key data of the crane in real time, which is convenient for timely adjustment of operation plans or troubleshooting. The intelligent dispatching system is also a practical optional function. The system can automatically analyze information such as cargo distribution and hoisting sequence, and optimize the crane's operation path and dispatching plan accordingly, thereby significantly improving operating efficiency. When selecting these optional accessories, it is important to consider factors such as actual use requirements, working environment, and budget to ensure that the selected accessories can fully exert their effectiveness and maintain a good cost-effectiveness.
When installing and replacing crane accessories, the relevant national and industry regulations and operating manual requirements must be strictly followed. Specifically, before installing new accessories, the accessories should be fully inspected to confirm that their models and specifications meet the design requirements, and their performance parameters are verified to be compatible with other parts of the equipment. At the same time, the installation location and method should be accurately planned and implemented to ensure that all installation holes are accurate and the connection parts are reliably tightened. After the installation is completed, the necessary debugging and testing procedures should be carried out to verify that the new accessories have been correctly installed and achieve the expected functional effects. When it is necessary to replace existing accessories, in addition to the above requirements, special attention should be paid to compatibility and matching with the original equipment. It is very important to provide systematic training for operators. Through professional guidance, they can be familiar with the operation process and precautions of new accessories, improve their operation skills and safety awareness, and ensure that the entire operation process is both efficient and safe.
We provide customers with a full range of technical consulting services. From equipment selection, solution design to installation and commissioning, there are professional teams to provide detailed guidance and support. In the equipment selection stage, we will recommend the most suitable product model to customers based on customer needs, budget and actual application scenarios. In the solution design stage, we will provide customized solutions based on customer needs and on-site environment to ensure the installation and use of the equipment to achieve the best results. During the installation and commissioning stage, our professional technicians will provide on-site guidance or remote assistance to ensure the smooth installation and commissioning of the equipment. Through comprehensive technical support, we help customers better understand and use our products and improve the performance and benefits of the equipment.
We provide a full range of repair and maintenance services to ensure the stable operation and long-term benefits of the equipment. For equipment troubleshooting and resolution, our professional maintenance team has rich experience and advanced technical means to quickly locate and solve problems. In order to ensure the long-term stable operation of the equipment, we also provide regular maintenance and maintenance services. Through regular inspection, cleaning, lubrication and other maintenance measures, the service life of the equipment can be effectively extended. At the same time, we have established a complete spare parts inventory and procurement channels to ensure timely provision of spare parts replacement services for customers.
We provide customers with professional training and technical support solutions, including operator training and technician training. Through systematic training and guidance, we improve customers' operating skills and equipment management capabilities. Operator training mainly covers basic product operations, daily maintenance and precautions, helping customers to master the various functions and usage methods of the equipment. Technician training focuses on product principles, performance parameters, fault diagnosis and handling, etc., to improve customers' understanding of equipment and maintenance capabilities. In order to continuously support customers, we also provide regular technical support and update services. Through regular technical support, we help customers keep abreast of the latest technical trends and product information, and enhance customers' competitiveness in the industry.
