25 ton castin overhead crane usually used in plant price

Topic starter 30/03/2023 11:54 am

The selling price of this 25 ton single girder overhead crane in Canada is $12954. If you purchase a large quantity, the purchase price of a single crane can be as low as $10869. The price of an overhead crane has a great relationship with its parameters. If you are planning to purchase this 25 ton single girder overhead crane, please leave your contact information and crane parameters below.

LD type 25 tons electric hoist single girder overhead crane main details in the table:

Span	S(m)	7.5	10.5	13.5	16.5	19.5	22.5	25.5	28.5
Lifting height	m	9	9	9	9	9	9	9	9
Lifting speed	m/min	7	7	7	7	7	7	7	7
Trolley speed	m/min	20	20	20	20	20	20	20	20
Crane speed	m/min	20	20	20	20	20	20	20	20
Lifting motor	kw	13	13	13	13	13	13	13	13
Trolley motor	kw	0.8	0.8	0.8	0.8	0.8	0.8	0.8	0.8
Total weight	t	3.26	3.76	4.4	5.17	5.92	7.48	9.71	14.05
Max Wheel Load	KN	51.3	55.3	58.4	61.3	63.9	68.2	74.2	85.4
Track		P24	P24	P24	P24	P24	P24	P24	P24
Main dimension	mm	7.5	10.5	13.5	16.5	19.5	22.5	25.5	28.5
Rail top to main top	H1	720	720	820	875	875	925	1100	1200
Rail top to hook centre	H2	1850	1850	1850	1900	1940	2000	1920	1920
Wheel base	W	2000	2000	2000	2500	2500	3000	3500	4000
Crane width	B	2500	2500	2500	3000	3000	3500	4000	4700
Hook left limitation	S1	1293	1293	1293	1293	1293	1293	1293	1293
Hook right limitation	S2	1893	1893	1893	1893	1893	1893	1893	1893
Main girder height	H3	900	900	1000	1100	1140	1250	1350	1450
Note: Control mode for ground operation.
