HD European standard overhead crane is small in size, light in weight and has low wheel pressure. Compared with conventional cranes, HD Euro-standard overhead cranes have the shortest critical distance from the crane hook to the wall, allowing for better use of factory space.It is widely used in the workshops, warehouses and other materials handling occasions of machinery manufacturing, petroleum, petrochemical, port, railway, civil aviation, electric power, food, paper, building materials, electronics and other industries.
Product name
HD European Overhead Crane
Lifting capacity
1~20ton
Lifting height
6-18m
Span
7.5m-28.5m
Working class
A5 (FEM 2M)
Crane material
Q235B
Lifting mechanism
ND european standard hoist
Trolley speed
2~20m/min
Crane speed
3~30m/min
Product description:
HD series electric hoist European crane is based on international standard: DIN (Germany), FEM (Europe), and CE,ISO (International),working class A5.The driving mechanism adopts SEW three- in-one reducer . Its superior performance is reflected in the mature application of technologies such as modular design, variable frequency speed regulation, and automatic detection. Various protection functions such as overload protection, overcurrent protection, and voltage loss protection complete the electric single girder bridge crane.
