The 2 ton overhead crane is sold for $5200, which is a European type overhead crane with excellent performance.
HD type single girder overhead crane ntroduction
HD series electric hoist European crane is our new designed crane for the low workshop and high lifting height demands. Its technology is advanced and design is based on international standard: DIN (Germany), FEM (Europe), and CE,ISO (International),working class A5.
Applications of HD type single girder overhead crane
HD series single girder electric hoist European crane is widely used in many kinds of workshop and warehouse with low headroom,but need more lifting height. such as accessories manufacturing workshop. Glass warehouse. Power plant. Heavy materials logistic. paper making, steel manufacturing workshop and other material handling plant.
Advantages of HD type single girder overhead crane
Smaller Dead Weight
Compact steel structure
Working Performance better
Speed is variable with inverter
Working stable and safe
Less Maintenance
Low Cost High Performance overhead crane with hoist for warehouse' s main parameters in follow:
Span(m) | 9.5 | 11 | 12.5 | 16 | 19.5 | 22.5 | 24 |
Lifting Height(m) | 6 9 12 15 18 | ||||||
Working Group | A5(2m) | ||||||
Lifting Speed(m/min) | 0.5/5 | ||||||
Hoist Weight(kg) | 928 | ||||||
Crane Weight(kg) | 3260 | 3596 | 3896 | 4889 | 5913 | 7527 | 7975 |
Track(recommend) | P38 | ||||||
Power Rate(kw) | 12.66 | ||||||
Max Wheel Load(kn) | 51.85 | 54.44 | 57.7 | 60.83 | 64 | 67.26 | 71.36 |
