LB type explosion-proof bridge crane (without main beam)
HD electric single beam overhead crane (without main beam)
Part 1:
Part 2:
Part 3:
The LB crane is an explosion-proof version of the LD type electric single beam crane, which is used in conjunction with explosion-proof electric hoists such as BCD and BMD. It has become a lightweight and small crane that operates on rails, with a suitable lifting capacity of 1-16t, a suitable span of 7.5-22.5m, a working level of A3-A5, and a working environment temperature range of -25-+40 ℃. This product is a general purpose crane, mainly used in places with low frequency of use or low rated lifting capacity lifting times such as mechanical manufacturing, assembly, and warehouses. Advantages: Short ordering cycle, cost-effective; Disadvantages: The effective lifting height is relatively low, the shaking during use is relatively large, the working level is low, and it is not suitable for heavy workshops. This crane is equipped with three types of control modes: ground, control room, and remote control. The control room also has two types of door opening modes: end face and side face, for users to choose from.
The LB (LBD) explosion-proof electric single beam crane has the characteristics of reasonable structure, beautiful appearance, and strong explosion-proof performance. The whole machine is used in conjunction with HB (BCD) and HBS (BMD) explosion-proof electric hoists, with a lifting capacity of 1-10 tons, a span of 7.5-22.5 meters, a working level of A3-A5, and a working environment of -25 ℃ to+40 ℃.
This product is widely used in factories, warehouses, and material yards of chemical units. It has two forms: ground and driver's cab. The driver's cab is divided into open and closed types, and the installation form is divided into left and right. The entrance direction is divided into side and end faces, allowing users to choose according to their respective usage situations.
This product is suitable for use in flammable and explosive environments. Explosion proof grade dIIBT4
This product has two operation modes: ground and operation room. There are two types of control rooms: open and closed. They can be installed on the left or right side according to the actual situation. The entrance direction has two types: side and end, to meet the needs of users in various situations.
HD crane is a kind of low headroom crane, usually used in factory workshops with low space height, which can effectively use the space height and increase the lifting height.
The HD electric single-girder crane is independently developed and designed on the basis of introducing advanced European design and manufacturing technology and combining the latest domestic standards such as GB3811-2008 and JB/T1306-2008. The appearance is beautiful, and the driving mechanism adopts KONE three-in-one reducer (hard tooth surface reducer, frequency conversion brake motor), which is completely comparable to similar European products in terms of appearance and technical performance. Its superior performance is reflected in the mature application of modular design, frequency conversion speed regulation, automatic detection and other technologies, and various protection functions such as overload protection, overcurrent protection, and voltage loss protection make the electric single beam more perfect.
HD electric single-girder crane is suitable for working in the environment conditions of working level A3～A5, working environment temperature -25℃～+40℃, relative humidity ≤85% and no flammable, explosive or corrosive medium. The lifting capacity is 1-16 tons, and the span is 7.5-25.5 meters. The crane power supply is three-phase AC with a rated frequency of 50Hz or 60Hz. The rated voltage is 220V ~ 660V. The upper and lower limits of the allowable voltage fluctuation of the motor are ±10%, and the internal voltage loss of the crane is not more than 3%.
We are a crane manufacturer located in China, providing crane customization services to global crane customers. If you want to customize a overhead crane, you can leave a message on the website or email us: sales010@cranesdq.com, tell us the following information, and our sales manager will contact you:
